Specifications
Application
LM1 EPDM the flexible discharge hose for use in breweries and the food and beverage industries.
Suitable for use with alcohol (max. 40%) and soft drinks, fatty (max. 36%) and non-fatty foods.
Feature
We don't use for the tube compound of LM1 EPDM any
PHTHALATES
PAH we comply with requirements of EU 1907/2006 (REACH), Annex XVII Nr. 50
Standard/Approval
BfR XXI Kat. 2, FDA (CFR 21 § 177.2600), EG1935/2004.
REACH regulation and REACH consumer goods annex XVII
Temperature range
-35°C / +95°C, steam cleaning without pressure up to 130°C / max. 30 min.
Safety factor
3,15 : 1
Tube
EPDM, white, food quality, smooth.
Reinforcement
Textile wrapped.
Cover
EPDM, red, resistant to ozone and weather, abrasion resistant, cloth impression.
Marking
continuous mylartape, white letters: "SEMPERIT (S) LM1-EPDM Lebensmittel BfR XXI Kat.2 BREWER/KELLERMEISTER D food quality FDA WP 12 BAR Made in EU".
Notice
Very high resistance to many aggressive cleaning agents.
For the application of cleaning agents please see our separate information sheet.
ATTENTION: Not suitable for dry conveyance.
Technical details
| Article number | Internal-Ø | Wall width | External-Ø | Work. pressure (max.) | Number of inserts | Bending radius (min.) | Weight approx. | Coil length (max.) | |
|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | mm | bar | mm | kg/m | m | ||
| 48256 1350 | 13.0 | 1/2 | 5.0 | 23.0 | 12 | 2 | 50 | 0.40 | 40 |
| 48256 1950 | 19.0 | 3/4 | 5.0 | 29.0 | 12 | 2 | 100 | 0.55 | 40 |
| 48256 2560 | 25.0 | 1 | 6.0 | 37.0 | 12 | 2 | 150 | 0.85 | 40 |
| 48256 3280 | 32.0 | 1 1/4 | 8.0 | 48.0 | 12 | 4 | 170 | 1.45 | 40 |
| 48256 3890 | 38.0 | 1 1/2 | 9.0 | 56.0 | 12 | 4 | 200 | 1.85 | 40 |
| 48256 4010 | 40.0 | 10.0 | 60.0 | 12 | 4 | 250 | 2.25 | 40 | |
| 48256 5011 | 50.0 | 11.0 | 72.0 | 12 | 4 | 350 | 2.95 | 40 | |
| 64256 6512 | 65.0 | 12.0 | 89.0 | 12 | 4 | 450 | 4.15 | 40 | |
| 64256 7515 | 75.0 | 15.0 | 105.0 | 12 | 6 | 550 | 5.95 | 40 | |
| 64256 8015 | 80.0 | 15.0 | 110.0 | 12 | 6 | 600 | 6.25 | 40 | |
| 64256 0015 | 100.0 | 15.0 | 130.0 | 12 | 6 | 700 | 7.60 | 40 | |
Vacuum resistance up to -0.5 bar (up to including 50mm ID), bigger sizes -0,3 bar
