SEMPERJET 250
General
Tube
Synthetic rubber, resistant against cold and hot water with usual cleaning agents
Reinforcement
One braid of high tensile steel wire
Cover
Abrasion and ozone resistant synthetic rubber
Standard cover: Black, blue or grey
(Available on request with black, blue and grey cover acc. to committee for Product Safety AfPS GS 2019:01 / Category 2 b.)
Temperature range
-10°C to 155°C / 14°F to +310°F
Standard branding
Embossed tape
Note
Not suitable for steam and oil hydraulic applications
Technical details
| Nominal | Internal-Ø | Braid-Ø | External-Ø | Work. pressure (max.) | Min. burst pressure | Bending radius (min.) | Weight approx. | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | dash | mm | inch | mm | inch | mm | inch | bar | psi | bar | psi | mm | inch | lbs/ft | kg/m |
| 6 | 1/4 | -4 | 6.6 | 0.26 | 10.0 | 0.39 | 11.8 | 0.46 | 250 | 3625 | 1000 | 14505 | 35 | 1.4 | 0.11 | 0.16 |
| 8 | 5/16 | -5 | 8.3 | 0.33 | 11.7 | 0.46 | 13.7 | 0.54 | 250 | 3625 | 1000 | 14505 | 65 | 2.6 | 0.14 | 0.21 |
| 10 | 3/8 | -6 | 9.9 | 0.39 | 13.5 | 0.53 | 16.5 | 0.65 | 250 | 3625 | 950 | 13780 | 75 | 3.0 | 0.19 | 0.29 |
| 12 | 1/2 | -8 | 13.0 | 0.51 | 17.1 | 0.67 | 19.5 | 0.77 | 250 | 3625 | 840 | 12185 | 100 | 3.9 | 0.26 | 0.39 |
